Reproducible Research: Why and How

class: center, middle, inverse, title-slide

# Reproducible Research: Why and How
## Part 3: Analytic Solutions
### Sam Harper
### <br> </br>
### SER Pre-Conference Workshop <br> 2020-10-30 </br>

---

class: center, top, inverse
# .orange[**3. Analytic Solutions**]

--
.left[
## .orange[**3.1 Workflow Management**]
## .orange[**3.2 Documentation**]
## .orange[**3.3 Literate Programming**]
## .orange[**3.4 Version Control**]
## .orange[**3.4 Dynamic Documents**]
]

---
class: center, top, inverse
# .orange[**3. Analytic Solutions**]

.left[
## .orange[**3.1 Workflow Management**]
## .gray[3.2 Documentation]
## .gray[3.3 Literate Programming]
## .gray[3.4 Version Control]
## .gray[3.4 Dynamic Documents]
]

---
# Workflow Advice
.pull-left[
Resources for advice on:
- Planning and organization
- Documentation
- Writing / debugging syntax
- Automating your work
- Variable labeling / naming
- Cleaning
- Archiving

Often specific to software but core ideas are the same.
]

.pull-right[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/long-miguel.png" width="1731" />

]

.footnote[ Long [(2009)](https://www.stata.com/bookstore/workflow-data-analysis-stata/); Christensen et al. [(2019)](https://www.ucpress.edu/book/9780520296954/transparent-and-reproducible-social-science-research)]
---
# Great online **free** resources for *R*
.footnote[See the series at [bookdown.org](https://bookdown.org/)]

.pull-left[
Technical help for:
- Learning *R*.
- Developing a reproducible workflow.
- Tips & tricks.
- Integration with other software.
- Dealing with frustration.*
]
.pull-right[
.center[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/rmarkdown-books.png" width="70%" />
]]

*Which is inevitable.

---
# Planning your work
.pull-left[
### Why?

Will save you time.

Plans should help you stay on track.

Hard, and isn't "fun".
]

.pull-right[
### What:

- Goals and publishing plans
- Scheduling
- Division of labor
- Datasets needed
- Variable names and labels
- Missing data procedures
- Analysis
- Documentation
- Backing up / archiving
]

---
.footnote[Image credit: [OSF](https://osf.io)]
### Planning for the entire research pipeline
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/osf-reproducible-workflow.png" width="1571" />

---
# Use projects to keep things organized
.footnote[Jenny Bryan on Project-oriented [workflows](https://www.tidyverse.org/articles/2017/12/workflow-vs-script/). Also possible with [SAS](https://documentation.sas.com/?docsetId=egug&docsetTarget=n1v9z6rladl7jan1tsq9clpzrzo2.htm&docsetVersion=8.2&locale=en).]

.pull-left[
RStudio: .blue[File > New Project...]
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/new-rstudio-proj.png" width="1571" />
]

.pull-right[
Stata: .blue[File > New > Project...]
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/new-stata-proj.png" width="1731" />
]

---
# Why Projects?
By definition, the directory `/User/samharper/project/data` is not reproducible.
But `project/data` works anywhere.
--

.right-column[
### Self contained and portable
### Easy to integrate with version control
### Working directory set at project location when opened
### Fresh session when project is launched
]

---
## File organization
.left-column[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/tree-directory.png" width="1048" />
]

.right-column[
### Core idea is to separate raw data, analytic data, code, and outputs.

### Why?
- Raw data is **never** altered.
- Separating code from data streamlines re-analysis.
- Outputs (tables, figures) are transient and should be easily regenerated from data + scripts.
]

---
.pull-left[
### Look familar?
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/file-org-bad.png" width="80%" />
]

.pull-right[
### That's more like it.
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/file-org-good.png" width="1195" />
]

---
# Many variations (Project TIER scheme)
.footnote[(https://projecttier.org)]

.left-column[
Also consider including a folder or file for 'metadata'.

Helps computers find your research!
]
.right-column[
.center[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/tier-folders.png" width="80%" />
]]

---
class: center, top, inverse

# .background[x]

# .orange[Tip: Don't obsess about rigidly following someone else's workflow.]

# .orange[**Important thing is to find a workflow that works for you.**]

---
# Your turn (finally!): Create a project
- Use RStudio or Stata (or something else) to create a new project
- Call it 'myproject'
- Create folders for `data`, `code`, and `output`.

- Now close the program.
- Browse to where the program file exists and double-click.
- Where is the current directory located? (Hint: type `getwd()` into the R console or `pwd` in the Stata command line).

--
- Are you in the right location?
✅ if yes, 🛑 if no

---
.left-column[
.footnote[ Example from Long (2009)]
Can also be embedded in the context of a much larger project structure.

Note that "\Source" and "\Derived" data are never in the same folder.
]

.right-column[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/long-directory.png" width="2045" />
]

---
class: center, top, inverse
# .orange[**3. Analytic Solutions**]

.left[
## .gray[3.1 Workflow Management]
## .orange[**3.2 Documentation**]
## .gray[3.3 Literate Programming]
## .gray[3.4 Version Control]
## .gray[3.4 Dynamic Documents]
]

---
class: center, middle

# "It is always faster to document it today than tomorrow."
.right[
# *-J Scott Long*
]
---
.pull-left[
### What should be documented?
- Data sources

- Data decisions
- Statistical analysis

- Software

- Storage
]

.pull-right[
### Levels of documentation
- Research log

- Codebooks

- Dataset documentation
]

---
# Research Log
.left-column[
<img src="03-analytic_files/figure-html/unnamed-chunk-13-1.png" width="100%" height="100%" />
]

.right-column[
The research log should help with:
- Keeping the work on track. Ideas, decision about analysis, papers you read that are relevant...document your thinking!

- Dealing with interruptions.

- Facilitating replication by others (especially by you 6 months later).

Ideally this should document what you did, why you did it, and how you did it.
]

---
### Alexander Graham Bell did it, so can you!
.center[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/bell-notebook-1876-03-09.png" width="80%" height="80%" />
]

.footnote[ [Image credit](https://commons.wikimedia.org/wiki/File:Alexander_Graham_Bell%27s_notebook,_March_9,_1876.PNG)]
---
### Example from a (poor) research log
Any format is fine (text, Word, markdown). Requires discipline, but pays dividends later.

---
## Codebooks
.pull-left[
Codebook is crucial, especially if you are collecting your own data.

Should include:
- Variable name and question number.
- Survey questions.
- Skip patterns.
- Descriptive statistics.
- Missing values and reasons.
- Data imputation.
]

.pull-right[
.center[Good advice 👇
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/icpsr-guide.png" width="70%" />
]
]

---
## Codebook example (Excel)
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/codebook-excel.png" width="2472" />

---
### Codebooks can also be automated (using R 📦 `codebook`)
.left[
Import dataset: `codebook_data <- rio::import("fakedata.dta")`
Generate codebook: `codebook(codebook_data)` 👇
]
.center[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/codebook-r.png" width="3557" />
]
---
# Dataset documentation
.pull-left[
### Why?
#### Provides key details about who, what, where, and which processes led to the created datasets.

### How?
#### Ideally, using a reproducible format that can be updated regularly.
]

.pull-right[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/costello-survey.png" width="1424" />
]

---
# One simple way: use a registry
.left-column[
Create a directory containing meta-data on each dataset created for the project.

Links directly to time-stamped source files that create data.
]

.right-column[
.center[
Dataset registry for `myproject`
Created by: NAME1
Last modified by: NAME2   ]

| Dataset        | Filename     | Date  | Source | Comments
|---------------|-------------|------:|-------:|--------:
| 1    | wave1.dta | 2020-09-01 | 01-build-w1.do | Fix missing
| 2     | wave2.dta      |   2020-10-05 | 02-build-w2.do | Ready to merge
| ... |   ...    | ...   | ...  | ...
]
---
class: center, top, inverse
# .orange[**3. Analytic Solutions**]

.left[
## .gray[3.1 Workflow Management]
## .gray[3.2 Documentation]
## .orange[**3.3 Literate Programming**]
## .gray[3.4 Version Control]
## .gray[3.4 Dynamic Documents]
]

---
class:

.left[# "Literate" programming is:]

.right-column[
# Code that humans understand.

# Computers will get it.
]

---
# Core ideas for coding practices

.right-column[
### Don't modify data by hand
#### This means no Excel for analysis, and no copy/paste.

### Don't point-and-click
#### Typing commands or graphical interfaces are not reproducible.

### Write code scripts
#### Coding creates reproducible workflow.
]

---
### More general coding advice
Comment extensively!

Short lines with no wrapping

Give functions, objects, and variables intuitive names:
- `edu_percent` 👍
- `v76` 👎

Label variables and values (remember codebook advice).

Avoid abbreviations for commands (Stata).

Consider breaking long files into several shorter ones.

---
.left-column[
### Essential parts of a syntax file

This example is for Stata, but the same principles apply to any software.
]
.right-column[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/stata-syntax.png" width="2285" />
]

---
background-image: url(../../images/sas-syntax.png)
background-size: contain
class: right, top

Same idea for SAS
---
### Similar for R, all are adaptable
When commenting *your* code, consider how you feel when you read someone *else's* code!
.pull-left[
```r
# PROJECT
  # Paper:
  # Authors:

# R Script
  # Purpose:
  # Created: <date> by <author>
  # Updated: <date>
  # Inputs: <files required>
  # Outputs: <tables and figures>

######## PACKAGES ########
# Check system for packages
  need <- c("dplyr", "foreign") # list packages needed

```
]

.pull-right[
```r
######## ANALYSIS ########
# First fit crude model
fit1 <- lm(...)

# Now add sets of confounders
fit1 <- lm(...)

# Non-linear model for binary outcome
fit3 <- glm(...)

######## ROBUSTNESS ########
# Exposure measured with error (95% Se)
# Quantitative bias analysis using
# parameters from Smith et al. (2014)
fit_corrected <- lm(...)
```
]

---
## Alignment, indentation, automation are your friends...

.pull-left[
### Harder to read
```s
keep sid class_id teacher grade1 ///
grade2 grade3 pass
```
### Without automation
```s
//  create binary variables without loop
generate y_lt2 = y<2 if !missing(y)
generate y_lt3 = y<3 if !missing(y)
generate y_lt4 = y<4 if !missing(y)
```
]

.pull-right[
### Easier to read
```s
keep   sid class_id teacher grade1 ///
       grade2 grade3 pass
```
### With automation
```s
//  create binary variables using a loop
foreach cutpt in 2 3 4 {
    gen y_lt`cutpt' = y<`cutpt' if !missing(y)
  }
```
]

---
## Save outputs as objects to insert into papers
.pull-left[
R:

```r
# a boring regression
lm(dist ~ 1 + speed, data = cars)

# save regression results for later
*fit <- lm(dist ~ 1 + speed, data = cars)
```
Note that `fit` contains our coefficients and SEs. Now write to a table:

```r
library(broom) # need broom pkg
write.csv( tidy( fit ), "t1.csv")
```
Now `t1.csv` has estimates.
]

.pull-right[
Stata:

```stata
webuse auto, clear

// another boring regression
regress price mpg
*estimates store m1
```
Here `m1` contains our model results. Write to a table:

```stata
// need eststo package
esttab m1 using t1.csv
```
Now `t1.csv` has estimates.
]

---
### Can be adapted to other software
.left-column[
Key idea:
- Results are *static* tables.

- Inserted into compiled manuscript.

- No copy/paste.
]

.right-column[
Example using SAS's **O**utput **D**elivery **S**ystem (ODS):
```sas
data etoh;
set analysis.analysis;
run;

ods select ParameterEstimates;
*ods csv file = "/home/sam.harper/Output/model.csv";
proc logistic data=etoh;
model drunk = free;
run;
ods csv close;
```
.orange[Results written to "model.csv" file]
]

---
# Structure and name files intuitively.
.footnote[See Jenny Bryan's [talk](http://www2.stat.duke.edu/~rcs46/lectures_2015/01-markdown-git/slides/naming-slides/naming-slides.pdf) on naming things.]
.left-column[
<img src="03-analytic_files/figure-html/unnamed-chunk-25-1.png" width="100%" height="100%" />
]

.right-column[
Give code, data files, and output logical names where possible.

Number scripts sequentially in the order they should be run, e.g.,:
- .blue[01_clean_data.R] (or .blue[.do, .sas, etc.])
- .blue[02_main_analysis.R]
- .blue[03_robust_checks.R]

Label output figures with descriptive names, but ones that aren’t likely to change (e.g., .blue[figure_hte.png] is better than .blue[figure_1.png])
]

---
# "One script to rule them all"

.left-column[
![](/Users/samharper/git/reproducibility-workshop-2020/images/frodo-ring.jpg)
]

.right-column[
### Many papers require multiple scripts.
### Dependencies create problems.
### Create a .blue[master-script] to run everything.
### Facilitates '1-click' reproduction.
]

---
### Example of a "master" script (Stata)
This is the content of `code/mvc-laws-master.do`:

```stata
capture log close master
log using "code/mvc-laws-master", name(master) replace text

//  program:  mvc-laws-master.do
//  task:     run all analyses
//  project:  mandatory seat belt laws and traffic deaths
//  author:   sam harper \ 23feb2017

// Required user-written programs: -tabout, -metan, -estout, -egenmore
// Can be downloaded by typing "ssc install tabout, replace"  and
// "ssc install metan, replace", etc. into the Stata command line

do "code/mvc-laws-data.do"                   // create analytic dataset
do "code/mvc-laws-analysis-descriptives.do"  // descriptive table
do "code/mvc-laws-analysis-models.do"        // model results
do "code/mvc-laws-analysis-appendix.do"      // appendix tables/figures

log close master
exit
```

---
### Your turn #2: Let's create a master script.

1) Open the `myproject` you created in R or Stata and create a new script (File>New File> R Script or File> New > Do-file. Type the following code:
- R: `print("Hello world!")`
- Stata: `disp "Hello world!"`

2) Save it as `1-hello.R` or `1-hello.do` in the "code" folder.

3) Repeat, creating another new script for `2-goodbye.R`, but type `"Goodbye world!"` instead of `"Hello world!"`

Now create a master script called `0-master.R`  or `0-master.do` that will run the two other scripts you created. The command to execute another file is `source` in R and is `do` in Stata.

4) Run the .blue[master] script.

- Success?
✅ if yes, 🛑 if no

---
.left-column[
## Something like?
]

.right-column[
.center[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/r-master-result.png" width="2413" />
]]

---
class: center, top, inverse
# .orange[**Break!**] ☕
<div class="countdown" id="timer_5fb30d3e" style="top:15%;right:0;bottom:15%;left:0;margin:5%;padding:50px;font-size:7em;" data-warnwhen="0">
<code class="countdown-time"><span class="countdown-digits minutes">10</span><span class="countdown-digits colon">:</span><span class="countdown-digits seconds">00</span></code>
</div>

---
class: center, top, inverse
# .orange[**3. Analytic Solutions**]

.left[
## .gray[3.1 Workflow Management]
## .gray[3.2 Documentation]
## .gray[3.3 Literate Programming]
## .orange[**3.4 Version Control**]
## .gray[3.4 Dynamic Documents]
]

---
.pull-left[
## Obligatory picture for every discussion of version control.
]
.pull-right[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/final-doc.png" width="90%" />
]

---
.left-column[
## But not a joke 😞
]

.right-column[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/no-joke.png" width="1541" />
]

---
## One kind of collaborative workflow

.pull-left[
### Collaborator 1:
- cleans data → `data.do`

- analysis → `analysis.do`

- generates Excel tables → `results.xls`

- draft manuscript in Word → `manuscript.docx`
]

.pull-right[
### Collaborator 2:
- adds new variables → `data_new.do`

- new analysis → `analysis2.do`

- new tables → `results_final.xls`

- revises draft with new results → `manuscript-v2.docx`
]

.center[
## This can work! But it can also create problems.
]

---
#What is the problem?
Which draft is the current one? Which set of tables contain the "right" results?
.center[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/vc-files.png" width="1279" />
]

---
## A version control system (VCS) automatically keeps track of changes to files and code.
.center[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/vc-image.png" width="600" height="400" />
]

---
## How can version control help?

.pull-left[
Under VCS the prior collaboration would only have 4 files:
- cleans data → .blue[data]

- analysis → .blue[analysis]

- generates results → .blue[results]

- generates manuscript → .blue[manuscript]
]

.pull-right[
A VCS keeps track of changes to each file.

We just don't usually see it.

]

---
## How can version control help?
.left-column[
![](03-analytic_files/figure-html/unnamed-chunk-35-1.png)
]

.right-column[
With version control you can:

- Collaborate
- Track each change and **who** made it
- Easily switch between versions of files (i.e. go backward in time)
- Compare versions of files
- Backup
- Work with the same files on different machines
- Collaborators can work simultaneously on the same files on different machines
- Experiment with a new version of code without permanently ruining anything
]

---
## Manual solutions (works, but not ideal)

.left-column[

]

.right-column[
Create dated versions of files (save-as) for each substantive change

With each modification, re-run ALL code to make sure nothing is broken—helps if you have a master file to run all scripts!

Check-in with coauthors to ensure multiple people aren't working on the same files at the same time.

Keep a simple log to remind yourself of the location/content of major changes.
]

---
## Software solutions

.right-column[
Version control software: helps manage versions and edits to files.

Git: Open-source, “distributed model” of version control developed by creator of Linux.

GitHub / GitLab: Free, web-based service that hosts Git “repositories” and offers a variety of features for collaboration:
- Online
- Desktop apps
- Command line (more technical)
]

---
How does Git work?
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/github-workflow-diagram.png" width="2200" />

---
# Advantages of Git

### Provides the entire narrative of your project.
### Allows you to go back in time.
### Experiment without breaking things.
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/git-hello-example.png" width="1712" />

---
### How is that better than Dropbox?
.left-column[
Simultaneous editing in Dropbox leads to "conflicted" copies of files.

Only one person can edit the "live" version of the file.

Can "rollback" to earlier version, but that affects everyone.

]

.right-column[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/strumpf-conflicted.png" width="2115" />
]

---
## Additional resources for Git
- The Basic Workflow of Git (an infographic explaining how Git’s version control system works): https://www.git-tower.com/blog/workflow-of-version-control

- Git + GitHub (information on using Git and GitHub in an R programming context): http://r-pkgs.had.co.nz/git.html

- GitHub’s Git [cheat sheets](https://services.github.com/resources/cheatsheets/) (reference sheets on the most commonly used Git commands)

- [GitHub Glossary](https://help.github.com/articles/github-glossary/) (a glossary of Git and GitHub terminology)

- [Pro Git](https://git-scm.com/book/en/v2) (Chacon & Straub, 2014; a complete manual of Git)

- [tryGit](https://try.github.io) (an interactive Web site for learning the basics of Git)

- Jenny Bryan's [HappyGit](https://happygitwithr.com/)

.footnote[Vuorre & Curley (2018)]

---
class: center, top, inverse
# .orange[**3. Analytic Solutions**]

.left[
## .gray[3.1 Workflow Management]
## .gray[3.2 Documentation]
## .gray[3.3 Literate Programming]
## .gray[3.4 Version Control]
## .orange[**3.4 Dynamic Documents**]
]

---
# What are dynamic documents?
Even with perfect (version controlled) code, you can still run into problems going from your code to paper.  (copy → paste problems)

### This is where dynamic documents come in.

A dynamic document includes your data, code, analysis, and output all in one place.

Fully automated so no mistakes from copying and pasting.

Several formats, but most commonly using R Markdown in RStudio or Markdoc in Stata.

---
.footnote[Krieger *PLoS* (2019)]
.center[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/krieger-workflow.png" width="90%" />
]

---
## How can dynamic documents help?

- Include tables by linking to a file, instead of a static image.
- Reference an estimate (e.g. risk ratio) by linking to a value calculated by an analysis file, instead of a static number typed manually.
- Automatically update tables and numbers if models and/ or data changes.
- Produce entire paper with one or two clicks.
- Most written using markdown language.

---
background-image: url(../../images/markdown-cheat.png)
background-size: contain

---
### Example of a whole paper written and submitted with Rmarkdown
.pull-left[
.center[`paper.rmd` ➡️
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/arph-rmd.png" width="80%" />
]]

.pull-right[
.center[➡️ `paper.pdf`
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/arph-pdf.png" width="1571" />
]]

---
.left-column[
### Stata catching up
Since Stata v15, now the `dyndoc` command can produce Word or HTML documents from Markdown.

More limited functionality than `markstat` but will likely improve.
]

.right-column[
.center[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/stata-dyndoc.png" width="2680" />
]]

---
# Main elements of a dynamic document
.right-column[
### Header information
#### Document metadata (author, title, date, formatting options).

### Document text
#### Write using markdown language (incl. equations, refs)

### Code: both 'inline' and as 'chunks'
#### Performs data maniupation, analysis, tables, figures.
]

---
## Header (also called YAML*)
.footnote[*YAML stands for YAML Ain't Markup Language. Ha.]
.pull-left[
Rmarkdown:
```yaml
---
title: "My Reproducible Paper"
author: Sam Harper
date: 2020-10-30
{{output: pdf}}
bibliography: myrefs.bib
csl: vancouver.csl
---
```
Other output formats available (e.g., .html or .docx output), many other formatting options.]

.pull-right[
Same structure for Stata Markdown:
```yaml
---
title: "My Reproducible Paper"
author: Sam Harper
date: 2020-10-30
abstract: |
  I give a brief summary here.
keywords: |
  markdown, reproducible research.
bibliography: myrefs.bib
---
```
Document format specified in another step.
]

---
## Document text
.pull-left[
Rmarkdown:
```yaml
---
header:
---
```

Text written using markdown language:
```md
# Introduction
This is why this paper is necessary, and here
are the gaps it will fill.

# Methods
## Data
We used some cool data.
```
]

.pull-right[
Same structure for Stata Markdown:
```yaml
---
header:
---
```
Can add references or equations as well:

```md
## Statistical analysis
We ran a linear regression [@Galton:1875]:

$$
y_{it}=\beta_{0} + \beta_{1}*X
$$

where $ \beta_{1} $ is what matters.
```
]

---
## Adding inline or 'chunks' of code
.pull-left[
Rmarkdown:
```yaml
---
header:
---
```
Document text including code 'chunk', set apart by 3 backticks:

```yaml
```r{eval=FALSE}
fit1 <- lm(y ~ x, data=d)
``````
Inline code: single backtick  `` `r
1+1` ``.

]

.pull-right[
Structure for Stata Markdown:
```yaml
---
header:
---
```
Same idea for code 'chunks':

```yaml
```s
// Write stata code inside chunks
sum mpg
``````
Inline: single backtick `` `s
r(mean)` ``.
]

---
### Allow text to update automatically when results change.
.pull-left[
Rmarkdown:

Header + document text followed by code chunk:

```yaml
```r{eval=FALSE}
fit1 <- lm(y ~ x, data=d)
est <- summary(fit1)$coefficients["x","Estimate"]
``````
We find x increases y by  `` `r
est` ``.

.blue[Will update if data or estimates change.]

]

.pull-right[
Structure for Stata Markdown:

Header + text with Stata code chunks:

```yaml
```s
reg price mpg
``````
Mpg increases price by `` `s
_b[mpg]` `` with a standard error of `` `s
_se[mpg]` ``.

.blue[These are dynamic values.]
]

---
### Stata markdown example (start at project directory)
.pull-left[
Stata do-file (`code/paper.do`) calls the markdown file using the `markstat` command:
```s
// change to writing directory
cd writing

// generate the manuscript
markstat using "paper.stmd", pdf

// back to the main directory
cd ..
```
]

.pull-right[
Markdown text (`writing/paper.stmd`)
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/markstat-markdown.png" width="1213" />
]

---
background-image: url(../../images/markstat-paper.png)
background-size: contain

---
background-image: url(../../images/sas-rmd-workflow.png)
background-size: contain
class: center, right
### Can be adapted to other software

---

.left-column[
### Rmarkdown + results from SAS

1. Use SAS to fit models, generate results.

2. Export results to files.

3. 'Knit' together with text using Rmarkdown.
]

.right-column[
<img src="/Users/samharper/git/reproducibility-workshop-2020/images/sas-pdf.png" width="947" />
]

---
class: center, top, inverse
# .orange[**Break!**] ☕
<div class="countdown" id="timer_5fb30d5b" style="top:15%;right:0;bottom:15%;left:0;margin:5%;padding:50px;font-size:7em;" data-warnwhen="0">
<code class="countdown-time"><span class="countdown-digits minutes">10</span><span class="countdown-digits colon">:</span><span class="countdown-digits seconds">00</span></code>
</div>
